TD2100 Professional TD-Class Power Amplifier - 2x2100W @8Ω High-Efficiency Touring Amplifier

Next-Generation Power Solution for Demanding Professional Audio Applications

The TD2100 represents a breakthrough in professional power amplification, combining Class AB sound quality with Class D efficiency through its innovative TD-class technology.

This 3U rack-mount powerhouse delivers 2x2100W at 8Ω (2x5000W @2Ω) with exceptional audio fidelity, engineered specifically for large-scale sound reinforcement, touring systems, and critical installations where reliability and performance are non-negotiable.

Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
kakao sharing button
snapchat sharing button
telegram sharing button
sharethis sharing button
  • TD2100

  • AUWAY

Description

Next-Generation Power Solution for Demanding Professional Audio Applications

The TD2100 represents a breakthrough in professional power amplification, combining Class AB sound quality with Class D efficiency through its innovative TD-class technology.

This 3U rack-mount powerhouse delivers 2x2100W at 8Ω (2x5000W @2Ω) with exceptional audio fidelity, engineered specifically for large-scale sound reinforcement, touring systems, and critical installations where reliability and performance are non-negotiable.



Innovative TD-Class Technology Advantages

Unmatched Power Efficiency

· TD-class hybrid architecture delivers 85%+ efficiency

· Advanced power conversion with 105V/μS slew rate

· Dual-mode operation (high-efficiency/audiophile modes)

· Intelligent power management for optimal performance

Reference-Grade Audio Performance

· <0.5% THD at 1/3 power (1kHz)

· 20Hz-20kHz (±0.5dB) flat frequency response

· >110dB signal-to-noise ratio for silent operation

· >400 damping factor for tight bass controlTD2100 power amplifier

Professional Power Specifications

· Stereo Mode: 2x2100W @8Ω / 2x3150W @4Ω / 2x5000W @2Ω

· Bridge Mono Mode: 4500W @8Ω / 6800W @4Ω

· Multi-voltage operation: 220V AC (50-60Hz)

· 3U heavy-duty chassis (483×565×130mm)



Engineered for Professional Demands

Premium Power Components

· Custom-wound toroidal transformer with pure copper windings

· Military-grade power transistor arrays for reliability

· Oversized heat sinks with smart thermal management

· Gold-plated connectors for optimal signal transfer

Intelligent System Protection

· Multi-stage protection circuitry:

· DC offset protection

· Over-temperature protection

· Short-circuit protection

· Infrasonic protection

· RF interference protection

Professional Monitoring

· Comprehensive status indicators:

· Active power

· Signal presence (-40dB)

· Clip warning

· Protection status



Ideal Professional ApplicatioNS

Large-Scale Live Events

· Main PA systems for stadiums and festivals

· Outdoor concert sound reinforcement

· Touring rigs for professional sound companies

Fixed Installation Venues

· Sports arenas and indoor stadiums

· Performing arts centers and theaters

· Megachurches and convention centers

Specialty Audio Systems

· High-power subwoofer arrays

· Distributed sound systems

· Temporary event installation


Specification

型号Model

TD2100

8Ω Stereo

2x2100W

4Ω Stereo

2x3150W

2Ω Stereo

2x5000W

8Ω Bridge

4500W

4Ω Bridge

6800W

Channels

2

Output Circuit

Class TD

Signal-to-noise ratio

>110dB

Conversion rate

105V/uS

Damping coefficient

>400

Frequency response

20Hz-20KHz ; ±0.5dB

Total harmonic distortion

≤0.5%, 1KHz, 1/3 Rated Power@8Ω

Transient intermodulation distortion

≤0.1%, 1KHz, 1/3 Rated Power@8Ω

Channel seperation

≥90dB

Input sensitivity

0.7V / 1V / 1.4V, BALANCE

Input impedance

10KΩ , BALANCE / 20KΩ , UNBALANCE

Indicator light

ACTIVE, SIGNAL(-40dB), CLIP(PEAK), PROTECTION

Power

220V ,AC 50Hz~60Hz

Net weight/Gross Weight

43.4KG / 48KG

Dimension(WxDxH)

483x565x130MM

Packing Size

745x570x198MM 1pcs/carton



Why Choose the TD2100?

 Industry-leading power density in 3U form factor

 TD-class efficiency with Class AB sound quality

 Military-grade reliability for 24/7 operation

 Intelligent protection systems for peace of mind

 Global touring ready with universal voltage compatibility


TD2100 power amplifier

power amplifier


TD2100 power amplifier

TD-class professional amplifier

Power amplifier
