A Class GB amplifier is a high-efficiency power amplifier that combines the audio quality of Class A/B designs with improved power efficiency. Class GB amplifiers typically achieve efficiency ratings of 60–70%, making them well-suited for demanding live sound and professional installation applications where both sonic performance and thermal management matter.
If you've spent any time specifying a professional sound system, you've likely encountered a long list of amplifier classes—Class A, Class B, Class AB, Class D, Class H, and more. Each represents a different approach to the same fundamental challenge: converting electrical power into audio output as efficiently and faithfully as possible.
Class GB sits in an interesting spot on that spectrum. It doesn't get as much press as Class D, and it's less familiar than Class AB. But for touring professionals and installation engineers who need high output, clean audio, and manageable heat dissipation, Class GB power amplifiers represent a genuinely compelling option.
This post breaks down how Class GB amplifier technology works, what efficiency actually means in this context, and where Class GB fits within a broader sound system amplification strategy.
Class GB is a variation of Class B amplifier design that uses a dynamically switching power supply. The core idea is straightforward: rather than operating from a single fixed supply voltage, a Class GB amplifier switches between two or more voltage rails depending on the instantaneous signal level.
At low signal levels, the amplifier draws from a lower voltage rail—consuming less power. As the signal increases and demands more headroom, the circuit switches to a higher voltage rail. This dynamic approach reduces the amount of power wasted as heat during low-level operation, which is where conventional Class AB designs are at their least efficient.
The "GB" designation reflects the generalized use of rail-switching borrowed from the Class G topology, but applied with the biasing characteristics associated with Class B operation. The result is an amplifier that maintains relatively linear performance across its output range while avoiding the thermal inefficiency of a fixed high-voltage design.
Efficiency in any power amplifier describes how much of the drawn electrical power actually reaches the speaker load, versus how much is lost as heat.
Class A amplifiers: ~15–35% efficient. High-quality sound, but enormous heat output and impractical for high-power applications.
Class AB amplifiers: ~50–65% efficient. The industry standard for decades, balancing quality and thermal performance.
Class GB amplifiers: ~60–70% efficient. A meaningful improvement over Class AB, achieved through dynamic rail switching without sacrificing audio fidelity.
Class D amplifiers: ~85–90% efficient. Highest efficiency, but historically associated with higher distortion and more complex filtering requirements (though modern Class D designs have closed this gap considerably).
For a Class GB power amplifier operating at high output levels—say, driving a large concert PA system—a 5–10% efficiency gain over Class AB translates directly into reduced power draw, lower operating temperatures, and longer component life. In a touring rack where amplifiers run for hours at a stretch, that thermal advantage is significant.
Efficiency is only one part of the picture. What distinguishes Class GB from other high-efficiency topologies is the combination of performance characteristics it offers across real-world operating conditions.
Class GB amplifiers maintain low total harmonic distortion (THD) figures across their operating range. A well-designed Class GB amplifier—like the Auway PA1.5—achieves THD+N of less than 0.05% at 8Ω and 1kHz, measured at one-tenth rated power. That figure is competitive with the best Class AB designs and well within the threshold of audibility for any practical application.
Professional-grade Class GB amplifiers deliver flat frequency response from 20Hz to 20kHz, typically within ±1dB. This means the amplifier adds minimal coloration to the signal across the full audible spectrum—an essential quality for live sound reinforcement, where accurate reproduction of the source material is the goal.
Damping factor describes how well an amplifier controls speaker cone movement. A higher damping factor means tighter, more accurate low-frequency reproduction. Class GB designs consistently deliver damping factors above 400, which supports clean, controlled bass response—particularly important for subwoofer applications and large-format speaker systems.
Because Class GB amplifiers generate less heat than Class AB at equivalent output levels, they can sustain higher output for longer periods without thermal throttling. The PA1.5, for example, uses four variable-speed cooling fans that adjust based on heatsink temperature, allowing the amplifier to run in sustained high-output environments without entering protective mute.
The right amplifier class depends on the application.
Choose Class GB if:
You need sustained high output power with better thermal performance than Class AB
Audio transparency and low distortion are priorities
The application involves long operating cycles, such as touring rigs or large permanent installations
You want a proven, robust design for demanding professional environments
Choose Class D if:
Weight and power consumption are critical constraints (e.g., ultra-compact touring rigs or battery-powered systems)
The application prioritizes energy efficiency above all else
Modern DSP-equipped Class D units are within budget and specification requirements
Choose Class AB if:
Budget is the primary driver
Output requirements are moderate
Thermal management infrastructure (rack ventilation, air conditioning) is already in place
For concert venues, megachurch sound systems, and high-power touring applications, Class GB represents a strong middle ground—offering the power density of Class AB with meaningfully better efficiency, without the tonal compromises that affected early Class D implementations.
The Auway PA1.5 is a practical example of what Class GB technology looks like in a production-grade unit. It delivers 2x1450W at 8Ω (or 2x2100W at 4Ω), with a bridged mono output of 4200W at 8Ω, housed in a reinforced 3U rack-mount chassis.
Key specifications that reflect the efficiency and reliability of the Class GB design:
Slew rate: 25V/μs for accurate transient response
Channel separation: >75dB at 8Ω and 1kHz
Connectivity: Balanced XLR inputs, Neutrik SpeakON outputs
Protection: DC fault detection, output relay switching, and thermal muting with automatic recovery
These specs place the PA1.5 firmly in the category of amplifiers suited for main PA duties in medium-to-large venues, high-power monitor systems, and permanent installations in performing arts centers or large conference facilities.
Class GB refers to an amplifier topology that uses dynamic rail switching—drawing from a lower voltage supply at low signal levels and switching to a higher voltage rail as signal demands increase. This reduces power waste and heat output compared to fixed-voltage Class AB designs, while maintaining comparable audio quality.
For high-output, sustained-use applications, Class GB offers better thermal efficiency than Class AB without significant trade-offs in audio performance. Class AB remains a cost-effective and well-understood option for moderate-power applications, so the better choice depends on output requirements, operating environment, and budget.
Class GB amplifiers typically achieve efficiency ratings between 60% and 70%, compared to 50–65% for Class AB and 85–90% for Class D. The improvement over Class AB is most pronounced during low-to-mid-level signal operation.
Yes. Class GB power amplifiers are well-suited for live touring applications. Their road-ready construction, high damping factors, and thermal efficiency make them reliable options for main PA and monitor systems in medium-to-large venues.
High-quality Class GB amplifiers achieve THD+N figures below 0.05% at standard test conditions, which is comparable to premium Class AB designs and suitable for professional sound system amplification where low distortion is a requirement.
Class GB amplifier technology delivers a practical efficiency gain over Class AB without forcing engineers to choose between thermal performance and audio quality. The dynamic rail-switching design reduces heat output, extends operating life, and cuts power draw during the sustained high-output operation that defines professional live sound and large-scale installation work.
For audio professionals specifying power amplifiers for concert venues, touring rigs, or permanent installations, Class GB is a category worth understanding thoroughly—and in many cases, worth specifying.
